Description
Motherboard Specification
• Processor Support: Intel® Core™ Ultra (Series 2) Processors, LGA1851
• Chipset: Intel® Z890
• Memory Support:
– 2 x DDR5 DIMM slots, up to 128GB
– Up to 9600+ MT/s (OC), Non-ECC, Un-buffered
– Dual Channel, XMP, AEMP III, DIMM Flex support
• Graphics Ports:
– 2 x Thunderbolt™ 4 ports (USB Type-C®, support DP and Thunderbolt video output)
• Expansion Slots:
– 2 x PCIe 5.0 x16 (x16 / x8+x8 / x8+x4+x4 depending on config)
– 2 x PCIe 4.0 x4
• Storage:
– 6 x M.2 slots total:
• M.2_1: PCIe 5.0 x4
• M.2_2: PCIe 4.0 x4
• M.2_3 & M.2_4: PCIe 5.0 x4 (share bandwidth with PCIEX16)
• DIMM.2_1 & DIMM.2_2: via ROG DIMM.2 module, PCIe 4.0 x4
– 4 x SATA 6Gb/s
• Ethernet:
– 1 x Realtek 5Gb LAN with ASUS LANGuard
• Wireless & Bluetooth:
– Wi-Fi 7 (802.11be) 2×2
– Supports 2.4/5/6GHz, up to 5.8Gbps
– Bluetooth® v5.4
• USB:
– Rear:
• 2 x Thunderbolt™ 4 (Type-C)
• 1 x USB 20Gbps (Type-C)
• 4 x USB 10Gbps (Type-A)
• 4 x USB 5Gbps (Type-A)
– Front:
• 1 x USB 20Gbps (Type-C, QC4+ 60W PD)
• 1 x USB 10Gbps (Type-C)
• 4 x USB 5Gbps via 2 headers
• 4 x USB 2.0 via 2 headers
• Audio:
– ROG SupremeFX 7.1 ALC4080 CODEC
– Up to 32-bit/384kHz playback
– Savitech AMP, gold-plated jacks, optical S/PDIF
– Rear I/O: 2 x gold-plated jacks + 1 x S/PDIF
• Internal I/O Connectors:
– CPU/Chassis/Water pump fan headers
– 4 x M.2 (Key M) + DIMM.2 slot
– 4 x SATA
– USB 20Gbps, 10Gbps, USB 5Gbps, USB 2.0 headers
– RGB: 3 x ARGB Gen 2, Light Bar, Aura
– Thermal sensor, BCLK, LN2 mode, Safe Boot, Retry, Start buttons
– PCIe mode switch, Debug ProbeIt points
• Back Panel I/O Ports:
– 2 x Thunderbolt™ 4 (Type-C)
– 1 x USB 20Gbps (Type-C)
– 4 x USB 10Gbps (Type-A)
– 4 x USB 5Gbps (Type-A)
– 1 x 5Gb Ethernet
– 1 x Wi-Fi module
– 2 x audio jacks + 1 x S/PDIF
– BIOS FlashBack™, Clear CMOS, PS/2 combo port
• Form Factor: ATX (30.5 cm x 24.4 cm)
